Ceramic Coated Stainless Steel Top
- PU coated aluminium alloy moulded body
- Single multi-turn intelligent knob operation
- Selection of hotplate or probe for temperature control
- Hot top indicator for user safety
- Adjustable temperature limit safety cut-off for top plate & probe
- Installed with double PT sensors for safety
- Timer indication of minutes & hours
- Set alarm for safety and ease of unsupervised operation
- Error code display for failures
- Smart recall of previous settings for quick setup
Technical Specification:
| Heating plate material | : | Ceramic Coated Stainless Steel |
| Dimension of heating plate | : | Ø 150mm |
| Three display windows for | : | Temp., RPM and Time |
| Speed range | : | 50 – 1500RPM |
| Heat output | : | 650 W |
| Heating capacity | : | 2 Ltr |
| Stirring capacity | : | 20 Ltr |
| Maximum Stirring bar Length | : | upto 80mm bar (at lower speed) |
| Temperature range | : | Ambient to 350°C Approx. |
| Adjustable safety cut off | : | 50 – 400°C |
| Control accuracy of PT 100 | : | ± 1K |
| Weight | : | 3.2 kg |
| Permissible ambient temp. | : | 5 – 40°C |
| Permissible relative humidity | : | 80% |
| Dimension of hot plate | : | 273 x 160 x 102mm |
| RS 232 interface | : | Yes (For Programming) |
| Frequency | : | 50/60Hz |
| Voltage | : | 230/115V |
| DIN EN 60529 | : | IP 32 |
